Applications
It’s suitable for granule, chunk, flakes products, such as snacks, cheese, pasta, candies, pet foods, IQF frozen foods…
Ideal for quantitative weighing of granule, slice, flake, roll or irregular shapes materials, such as candy, snacks, pasta, IQF frozen food, cheese, rice, pet foods and other non-food products.
Features
- Touch screen interface
- Language support
- IP65 waterproof and dustproof design
- Program and mechanism diagnostic function
- Auto-selection and one-plus two collecting hopper system
- High precision diagital weighing sensor
- 可调节孔径角的步进电机来获取n high precision
- High-Speed and High-Accuracy mode is optional to pick
- Combination bucket could dump orderly to avoid products jam up
- User friendly operation manual could read on the touch screen
- Powerful statistics function, recording every batch production data
- Pieces counting function
- Enclosed stainless steel construction
Technical Data
Weighing Range: 10‐2000g
Accuracy: ±0.5‐1.5g
Weighing Speed: Max. 120 Drops/Min
Hopper Volume: 2.5L
Driver: Step Motor
Options: Timing Dipper, Printer, Diverter Device, Rotary Top Cone
Control Panel: 10.4 inches large touch screen
Power Requirements: 220V,50/60HZ,10A,1.5KW
Machine Weight: 480KG
Packing Dimension: L1700 X W1100 X H1100MM
Mechanical Character
1. New designed machine case contributes to better stability.
2. Load cell detection under the top cone.
3. New actuator design reduces the mechanical vibration and improves the load cell value accuracy.
4. Arc-shaped machine frame and new machine body cover, improves stability and appearance.
Our Service
12 Months Guarantee
★ 12 months free main parts change (Please return the damaged parts by airmail)
★ Overseas engineers available (You only have to pay part of the freight)
Customization
All our machines can be customized , according to your product's features and your workshop environment, or your production line.
After-sales Service Provided
Engineers availbale to provide after-sales service overseas in order to help customers solve technical problems.
