ZL520 Auger filling and packaging machine for milk powder

Tanıtım :

This machine are special design for packing powder product into pillow bottom bag .It is widely use for packing wheat flour and chemical powder .This machine unit are including one set ZL2000 auger filling machine one set ZL520 vertical bag forming filling machine .one set Open mouth bag conveying machine and control system .The whole machine control by PLC and operate by color touch screen .

Bag carrying conveyor

Work progress:

1,Automatic weighing and discharge the material

2,Automatic making the bag and filling the material

3、自动放电输送机器上袋子with module

4,Sending the bag to manual vacuuming and sealing

Details information of the machine

1,ZL520 Vertical bag forming filling sealing machine

The unit of machine is especially developed for small bag packaging ,This machine can independently complete the bag making, filling (air filling or exhausting as option), sealing (hole punching as option ) code printing, and bag counting etc. adopt film automatic correction device .The machine frame and material contact part made by SUS304 .PLC and touch screen adopt by Siemens brand .Adopt Panasonic servo motor for horizontal sealing which is fast and stable .And Pneumatic parts adopt Air Tac brand .Main Electrical components adopt Omron and Schneider brand Which is easy to operation

Teknik parametreler

Weighing Range: 500-1000gram

Packaging Speed:20-50 bags/min

Bag size: (80-350)*(60-260)mm(L*W)

Basınçlı hava gereksinimi: 0.6Mpa 0.65m³/dak

Makara dış çapı: 400mm

Çekirdek iç çapı: 75mm

Makine ağırlığı: 800kg

Güç kaynağı: 5.5kW 380V± 50Hz

Ana Özellikler ve Özellikler:

A wide range of pouches: Pillow and Gusset pouches(option).

High speed: More than20-60 bags/min
